BEST Rapid Fast Battery Quick Charger & Adapter ALL-IN-ONE Universal Charger Cell Balancer Too

Rapid Fast Battery Quick Charger & Adapter Battery charger Adapter Universal Charger market. The Best ALL-IN-One Compact Universal Charger in the Market. Easy to read and use digital display makes charging any battery EXTREMELY simple. Buy this charger today and you will not regret it. Balances battery cells too.

Various Connectors Supported:

Hitech
JST
Deans
Tamiya
Traxxas
No extra hassle of trying to find connector adapters, or worrying about if your Hobby battery pack is supported.

Supports multiple types of battery packs with one single charger! The follow packs are supported:

NiMH/NiCD 1~15 cells ( 1.2v to 18v)
Li-PO/Lithium Ion 1~6 series ( 3.7v to 22.2v)
Li-Fe 1~6 series
Sealed Lead Acid (SLA)
Charger Specifications:

Handle NiMH, NICD, Li-Po,Li-ion, Li-Fe, SLA Batteries
Build-in Balance
Temperature Sensor
DC 11V~15V, which can be directly connect to Automobile Battery. The working electric current is less than 5A when it is charged in full load. The current of the fuse is 10A which could prevent short circuit.
Specification

Operating voltage
DC 11~18 volts
AC 100~240V, 50/60Hz

Charge/discharge power
max. 50/5 Watts

NiCd/MH
1~15 cells

LiIo/LiPo/LiFe
1~6 series

Pb
2~20V

Charge current
0.1 to 5.0A

Discharg current
0.1 to 1.0A

No. of cycle
1 to 5 times

Battery data memory
up to 5 data

Weight
1000g

Dimension
160x120x40 mm

User's setting-up parameters

Battery voltage type
LiIo:3.6V, LiPo:3.7V, LiFe:3.3V

NiCd Delta-peak voltage sensitivity
1 to 20mV

NiMH Delta-peak voltage sensitivity
1 to 20mV

Battery temperature cut-off
20 to 80C or OFF

Waiting time between charge/discharge
1 to 60 min.

Integral timer limit for safety
10 to 720 min.or OFF

Maximum charging capacity limit for safety
10 to 9990mAh or OFF

Key beep and buzzer sound
ON/OFF

Input DC power low alert
10 to 11V

Optimized operating software

When charging or discharging, TB6 has an 'AUTO' function that sets the feeding current or the cell count of the battery automatically. Especially for Li-ion/Li-Polymer batteries, it can prevent the over-charging can lead to an explosion by users fault. Every program in the unit is controlled with mutual links and communication for every possible error so it introduces a maximum safety. These can be set at users option.

Dual input power

TB6 employs the circuit that can be operated with the input power of AC(Alternating Current) or DC(Direct Current). For AC input, it contains a AC-DC switching power supplier which has 5A of power capacity and maximum output power of 50Watts for charging. As a result it can charge up to 16 cells of NiCd/NiMH and 6 series of Li-ion/Li-Polymer batteries with maximum current of 5.0A.

Individual voltage balancer for Li-ion/Li-Polymer batteries inside

TB6 has an individual-cell-voltage balancer inside. So it does not need any balancer separately when charging Li-ion/Li-Polymer batteries (LiIo/LiPo/LiFe) for cell voltage balancing.

Balance individual cells on discharge

TB6 also can monitor and balance individual cells of the battery pack during the discharge process. If the voltage of any one cell varies abnormally, the process will be stopped with the error message.

Accept various types of battery

TB6 can accept three types of batteries - LiIo, LiPo and LiFe. They have different characteristics by their chemistry. You can select any one of them that you are going to process before the job.

Battery 'Fast' and 'Storage' mode

You can charge Li-ion/Li-Polymer battery for special purposes. 'Fast' charge reduces the charging time of battery and 'Storage mode controls the final voltage of the battery to be suit for long time storage.

Data store/load

For users convenience it can store maximum 5 data of different batteries. You can establish the data contains program setting of the battery to charge or discharge continually. These data can be called out at any time you need and the process can be executed without program setting.

Cyclic charging/discharging

Perform 1 to 5 cycles of charge>discharge or discharge>charge continually for battery refreshing and balancing.

PC based analysis using USB communication

For technical expert, TB6 offers PC based program can analysis the characteristic of the battery by USB port. It shows a graph of voltage, current, capacity and temperature curves. It also shows the individual voltage of each cell in the battery pack.

Robust outer aluminum case

High-quality aluminum case is durable and very efficient to cool out the internal heat

Warning

Use special caution when working with Li-ion cells, they are very sensitive to charging characteristics and may explode if mishandled.

We are not responsible for any damage caused by misuse or mishandling of batteries in charging.

Do not make any changes to the charger, charger accessories or connectors, as this might cause electrical shortage, fire or over-heating during charging.

Constant Current Switch Power Supply

Input: 100-240V AC, 50/60Hz 2A

Output: 12V, 5A

Perfect for Micro-control LCD Li-Po Ballance Charger
